Value M2 Condensate Pump

VALUE M2 Condensate Pump with Built-in Tank

The VALUE M2 condensate pump (drain pumps) features a robust design with a built-in tank, making it ideal for various HVAC applications. Additionally, it operates efficiently at a flow rate of 40 liters per hour, and it is suitable for splits up to 45,000 BTU/hour (13 kW).

Furthermore, this ultra-quiet pump is not only reliable but also easy to install and maintain. Its user-friendly features include:

• Easy-to-clean tank for hassle-free maintenance
• Plug & play setup for quick installation
• Twist & click check valve for efficient operation
• Built-in bubble level for accurate positioning

In addition, the M2 is engineered for high reliability, as it performs well even in demanding conditions. It is equipped with a brushless DC motor, which ensures low noise and vibration. Moreover, key features include:

• Safety switch for added protection
• Warning LED to indicate operational status
• Probe sensor for precise water level detection

VALUE M2 Condensate Technical Features

• Power Supply: 220 V, 50 Hz
• Max Vertical Discharge Height: 12 meters
• Max Flow Rate: 40 liters/hour
• Tank Capacity: 200 ml
• Condensate Outlet Pipe Diameter: 6 mm
• Suitable for Mini Splits: Up to 45,000 BTU/hour (13 kW)
• Sound Level at 1 Meter: 19 dB(A)
• Ambient Temperature Range: 0-50 °C
• Dimensions: 163 x 86 x (h) 52 mm
• Tank Dimensions: 83 x 40 x (h) 83 mm

Ultimately, the VALUE M2 condensate pump combines compactness with efficiency. Therefore, it is an excellent choice for silent and durable operation in various HVAC systems.
